最近接到一个需求是需要在前端进行工作流流程图的设计，上网找了一圈轮子，最终还是选择了GG-editor，原因是这个界面看起来相对比较简洁，我也没什么专业编辑的需求。GG-editor是用蚂蚁金服的g6可视化引擎做的，而19年g6升级到了3.x版本，于是GG-editor的作者高力也把GG-editor重构升级到了3.x版本，但是由于3.x在本文写作时仍在重构阶段，文档残缺，所以我在使用了一段时间的新版本后仍然选择了2.0.4版本，之后若是升级我会再更一篇。
在使用3.x版本的时候我遇到了两个坑，一是undo命令会有bug，在2.0.4版本中，undo命令可以撤销位置移动操作，而在3.x版本中就不行了，在github上有issue但是作者并没有响应。二是如何保存流程图，在2.0.4版本中通过调用propsAPI.save()函数来实现（下面会贴代码），但是3.x版本中没有给出示例，我尝试在源码中全局搜索save函数结果没有搜到哈哈，不过我看最近作者在github的issue中回应说新版本需要用withEditorContext，和withPropsAPI用法一样 ，我没有具体尝试，之后若是升级会试一下。下面是在2.0.4版本中的保存示例，我自己加了一个弹窗确认：
import React from 'react';
import { connect } from 'dva';
import { Button, Modal, Form, Input, Icon } from 'antd';
import { withPropsAPI } from 'gg-editor';
import styles from './index.less'const CollectionCreateForm = Form.create({ name: 'save_template' })(// eslint-disable-next-lineclass extends React.Component {render() {const { visible, onCancel, onSubmit, form, isSubmitting } = this.props;const { getFieldDecorator } = form;return (<Modalvisible={visible}title="模板保存"okText="提交"onCancel={onCancel}confirmLoading={isSubmitting}onOk={onSubmit}><Form layout="vertical"><Form.Item label="模板名称">{getFieldDecorator('name', {rules: [{ required: true, message: '请输入模板名称!' }],})(<Input />)}</Form.Item><Form.Item label="描述">{getFieldDecorator('description')(<Input type="textarea" />)}</Form.Item></Form></Modal>);}},
);@connect(({ workflow, loading }) => ({workflow,isSubmitting: loading.effects['workflow/submitWorkflowTemplate'],
}))
class Save extends React.Component {constructor(props) {super(props);this.state = {modalVisible: false,};}showModal = () => {this.setState({ modalVisible: true });};handleCancel = () => {this.setState({ modalVisible: false });};saveFormRef = formRef => {this.formRef = formRef;};handleSubmit = e => {const { form } = this.formRef.props;const { dispatch } = this.props;form.validateFields((err, values) => {if (err) {return;}const { propsAPI } = this.props;const data = propsAPI.save();//将数据传换为接口所需参数let taskList = [];if (data.hasOwnProperty('edges')) {const edges = data.edges;for (let i in edges) {taskList.push({'task_id': edges[i].id,'upstream': edges[i].source,});}}const params = {name: values.name,description: values.description,task: taskList,};//上传成功后清空表单关闭弹窗dispatch({type: 'workflow/submitWorkflowTemplate',payload: params,}).then(res => {if (res && res.success) {form.resetFields();this.setState({ modalVisible: false });}});});};render() {const { isSubmitting = false } = this.props;return (<div className={styles.actionGroup}><div style={{ padding: 8 }}><Button onClick={this.showModal}><Icon type="save" />保存</Button></div><CollectionCreateFormwrappedComponentRef={this.saveFormRef}visible={this.state.modalVisible}onCancel={this.handleCancel}onSubmit={this.handleSubmit}isSubmitting={isSubmitting}/></div>);}
}export default withPropsAPI(Save);
关键代码其实就两处，一是组件要外包withPropsAPI（3.x版本要换成withEditorContext），二是从props中获取propsAPI，然后调用propsAPI.save()函数；
还有一个非常常见的需求就是将左侧拖拽区改造成树状结构，我看网上有不少人问，这里我贴一下我的解决方案。我去翻了一下antd的文档，发现树节点的标题是接受组件传入的：
所以我就进行了如下尝试，一试居然成功了：
import React from 'react';
import { Tree, Icon } from 'antd';
import { ItemPanel, Item } from 'gg-editor';
};export default FlowItemPanel;
当然这里的Item是我自己自定义的，直接复制粘贴怕是用不了。
待续
