请尊重他人的劳动成果，转载请注明出处：
http://blog.csdn.net/sw950729/article/details/52239548

最近改代码改的都醉了，前几天写了个图片加载框架，点了闪退，找半天没找到问题在哪- - 看来又要花心思重写了。好了。来说正文了。
上周花了一周的时间写了几个自定义view。有loading。有刷新，还有一些别的，因为最近在写个框架，所以耽误了。这个后期肯定会补上。先来看看，今天我们loading的效果：

其实这个不是很难，我居然花了两天半++。因为今天电脑太卡了。后面就只用文字表达，不上图片了。
首先我们看这个效果，这5个小圆是在一个大圆上，至于怎么获取这五个圆的位置，这是难点之一，到时候你们自己看代码理解，先上一些必用的定义：

 private static final String TAG = "SWLoadView";private Paint paint;private Path path;//大圆的半径private int bigRadius = 150;//小圆的半径private int smallRadius = 30;//移动圆的半径private int radius = 20;//存放圆的圆心private ArrayList<Circle> circlelist = new ArrayList<>();//移动的圆的圆心private ArrayList<Circle> offSetcircle1 = new ArrayList<>();private ArrayList<Circle> offSetcircle2 = new ArrayList<>();private ArrayList<Circle> offSetcircle3 = new ArrayList<>();private ArrayList<Circle> offSetcircle4 = new ArrayList<>();private ArrayList<Circle> offSetcircle5 = new ArrayList<>();private int width = 0;private int height = 0;//移动速度private int speed;private int count1 = 0;private int count2 = 0;private int count3 = 0;private int count4 = 0;private int count5 = 0;private int count6 = 0;private int count7 = 0;private int count8 = 0;private int count9 = 0;private int count10 = 0;

我们需要五个圆的圆心，以及动态滚动的球的轨迹，因为是5条线，所以这边我用了5个list来存放。代码如下：

 //依次放入五个圆心的坐标Circle circle1 = new Circle();Circle circle2 = new Circle();Circle circle3 = new Circle();Circle circle4 = new Circle();Circle circle5 = new Circle();circle1.circleX = (width / 2 + Math.abs((float) (bigRadius * Math.cos(60))));circle1.circleY = (height / 2 - Math.abs((float) (bigRadius * Math.sin(60))));circle2.circleX = (width / 2 + Math.abs((float) (bigRadius * Math.sin(120))));circle2.circleY = (height / 2 + Math.abs((float) (bigRadius * Math.cos(120))));circle3.circleX = (width / 2 - Math.abs((float) (bigRadius * Math.cos(180))));circle3.circleY = (height / 2 + Math.abs((float) (bigRadius * Math.sin(180))));circle4.circleX = (width / 2 - Math.abs((float) (bigRadius * Math.sin(240))));circle4.circleY = (height / 2 - Math.abs((float) (bigRadius * Math.cos(240))));circle5.circleX = (width / 2 + Math.abs((float) (bigRadius * Math.cos(300))));circle5.circleY = (height / 2 - Math.abs((float) (bigRadius * Math.sin(300))));circlelist.add(circle1);circlelist.add(circle2);circlelist.add(circle3);circlelist.add(circle4);circlelist.add(circle5);speed = (int) (circlelist.get(1).circleX - circlelist.get(2).circleX + 0.5);speed = speed / 20;for (int i = 0; i < speed; i++) {Circle circle = new Circle();circle.circleX = circlelist.get(0).circleX * (speed - i - 1) / speed + circlelist.get(1).circleX * (i + 1) / speed;circle.circleY = circlelist.get(0).circleY * (speed - i - 1) / speed + circlelist.get(1).circleY * (i + 1) / speed;offSetcircle1.add(circle);}for (int i = 0; i < speed; i++) {Circle circle = new Circle();circle.circleX = circlelist.get(1).circleX * (speed - i - 1) / speed + circlelist.get(2).circleX * (i + 1) / speed;circle.circleY = circlelist.get(1).circleY * (speed - i - 1) / speed + circlelist.get(2).circleY * (i + 1) / speed;offSetcircle2.add(circle);}for (int i = 0; i < speed; i++) {Circle circle = new Circle();circle.circleX = circlelist.get(2).circleX * (speed - i - 1) / speed + circlelist.get(3).circleX * (i + 1) / speed;circle.circleY = circlelist.get(2).circleY * (speed - i - 1) / speed + circlelist.get(3).circleY * (i + 1) / speed;offSetcircle3.add(circle);}for (int i = 0; i < speed; i++) {Circle circle = new Circle();circle.circleX = circlelist.get(3).circleX * (speed - i - 1) / speed + circlelist.get(4).circleX * (i + 1) / speed;circle.circleY = circlelist.get(3).circleY * (speed - i - 1) / speed + circlelist.get(4).circleY * (i + 1) / speed;offSetcircle4.add(circle);}for (int i = 0; i < speed; i++) {Circle circle = new Circle();circle.circleX = circlelist.get(4).circleX * (speed - i - 1) / speed + circlelist.get(0).circleX * (i + 1) / speed;circle.circleY = circlelist.get(4).circleY * (speed - i - 1) / speed + circlelist.get(0).circleY * (i + 1) / speed;offSetcircle5.add(circle);}

初始化不难：

private void inital() {paint = new Paint();path = new Path();paint.setStyle(Paint.Style.FILL);paint.setColor(0xff00ced1);paint.setAntiAlias(true);}

ondraw方法先画5个圆，以及一个滚动的球的路径：

protected void onDraw(Canvas canvas) {canvas.drawCircle(circlelist.get(0).circleX, circlelist.get(0).circleY, smallRadius, paint);canvas.drawCircle(circlelist.get(1).circleX, circlelist.get(1).circleY, smallRadius, paint);canvas.drawCircle(circlelist.get(2).circleX, circlelist.get(2).circleY, smallRadius, paint);canvas.drawCircle(circlelist.get(3).circleX, circlelist.get(3).circleY, smallRadius, paint);canvas.drawCircle(circlelist.get(4).circleX, circlelist.get(4).circleY, smallRadius, paint);drawBezier(canvas);invalidate();}

小球的滚动路径是用贝塞尔曲线绘画的，这也是难点之二。

if (offSetcircle1.get(count1).circleX != circlelist.get(1).circleX) {//根据角度算出四边形的四个点float offsetX = (float) (radius * Math.sin(Math.atan((offSetcircle1.get(count1).circleY - circlelist.get(0).circleY) / (offSetcircle1.get(count1).circleX - circlelist.get(0).circleX))));float offsetY = (float) (radius * Math.cos(Math.atan((offSetcircle1.get(count1).circleY - circlelist.get(0).circleY) / (offSetcircle1.get(count1).circleX - circlelist.get(0).circleX))));float x1 = circlelist.get(0).circleX - offsetX;float y1 = circlelist.get(0).circleY + offsetY;float x2 = offSetcircle1.get(count1).circleX - offsetX;float y2 = offSetcircle1.get(count1).circleY + offsetY;float x3 = offSetcircle1.get(count1).circleX + offsetX;float y3 = offSetcircle1.get(count1).circleY - offsetY;float x4 = circlelist.get(0).circleX + offsetX;float y4 = circlelist.get(0).circleY - offsetY;float anchorX1 = (x2 + x4) / 2;float anchorY1 = (y2 + y4) / 2;float anchorX2 = (x1 + x3) / 2;float anchorY2 = (y2 + y4) / 2;path.reset();path.moveTo(x1, y1);path.quadTo(anchorX1, anchorY1, x2, y2);path.lineTo(x3, y3);path.quadTo(anchorX2, anchorY2, x4, y4);path.lineTo(x1, y1);path.close();canvas.drawCircle(offSetcircle1.get(count1).circleX, offSetcircle1.get(count1).circleY, radius, paint);canvas.drawPath(path, paint);count1++;} else if (offSetcircle1.get(count1).circleX == circlelist.get(1).circleX && offSetcircle1.get(count2).circleX != circlelist.get(1).circleX) {//根据角度算出四边形的四个点float offsetX = (float) (radius * Math.sin(Math.atan((offSetcircle1.get(count2).circleY - circlelist.get(1).circleY) / (offSetcircle1.get(count2).circleX - circlelist.get(1).circleX))));float offsetY = (float) (radius * Math.cos(Math.atan((offSetcircle1.get(count2).circleY - circlelist.get(1).circleY) / (offSetcircle1.get(count2).circleX - circlelist.get(1).circleX))));float x1 = circlelist.get(1).circleX - offsetX;float y1 = circlelist.get(1).circleY + offsetY;float x2 = offSetcircle1.get(count2).circleX - offsetX;float y2 = offSetcircle1.get(count2).circleY + offsetY;float x3 = offSetcircle1.get(count2).circleX + offsetX;float y3 = offSetcircle1.get(count2).circleY - offsetY;float x4 = circlelist.get(1).circleX + offsetX;float y4 = circlelist.get(1).circleY - offsetY;float anchorX1 = (x2 + x4) / 2;float anchorY1 = (y2 + y4) / 2;float anchorX2 = (x1 + x3) / 2;float anchorY2 = (y2 + y4) / 2;path.reset();path.moveTo(x1, y1);path.quadTo(anchorX1, anchorY1, x2, y2);path.lineTo(x3, y3);path.quadTo(anchorX2, anchorY2, x4, y4);path.lineTo(x1, y1);path.close();canvas.drawCircle(offSetcircle1.get(count2).circleX, offSetcircle1.get(count2).circleY, radius, paint);canvas.drawPath(path, paint);count2++;}

这快是绘画的右下2个小球的路径，先从小球的头部从1-2，然后小球的尾部从1-2.后面的就是复制粘贴了。因为是5条线，所以是10个动画轨迹，头过去–尾过去。
代码我已经上传到csdn上了，地址：http://download.csdn.net/detail/sw950729/9606812。一开始准备上传到github上的，结果不会搞 0 0 。
最近也是无意了写了不少自定义view的动画。如果有好的动画效果或者思路可以提出来，我会抽空试着写一写~~
好了。有兴趣交流的，请看左上角的群号，欢迎进入。
